Visible and infrared photographs of a middle latitude storm are
shown below (the large L shows the surface center of low
pressure). At A the clouds are white on the visible
photograph and grey on the IR photograph. At B the clouds
are white on both the visible and the IR photographs. The
cloud at C is white on the IR photograph and grey on the visible
picture. Based on these satellite observations, use an A, B,
or C to indicate where the following types of clouds are found in
the storm.
thunderstorm (Cb) clouds________ thin,
high altitude, Cs clouds________ thick,
low altitude St clouds________
click here when you think you
have the answers.
